| # | Characteristics | Specifications |
|---|---|---|
| 1 | Model | GPS Master Clock |
| 2 | Input | From GPS Satelite via GPS Antenna |
| 3 | Indication | 6 digits 100mm Super Bright Red LED (HH:MM:SS) |
| 4 | Indication Accuracy | +/- 1 second |
| 5 | Programming | 4 key membrane keypad |
| 6 | Calibration | Software based |
| 7 | Power Supply | 230 V AC, +/- 10% (other options on demand) |
| 8 | Mounting | Wall Mounting and Hanging for ceiling both options in-built |
| 9 | Dimensions | 408 x 168 mm, Depth: 70 mm |
| 10 | Optional | Available in Panel Mounting 410 x 170 mm cutout |
| 11 | Antenna | Magnetic based GPS Antenna with 2 meter cable |
