| # | Characteristics | Specifications |
|---|---|---|
| 1 | Model | Sleek 901C-6 |
| 2 | Input | 4-20 mA / 0-20 mA / 0-10 V / from Load Cell |
| 3 | Indication | 6 digits 100mm Super Bright Red LED |
| 4 | Indication Accuracy | +/- 0.25% of full scale +/- 1 digit |
| 5 | Programming | 4 key membrane keypad |
| 6 | Calibration | Software based |
| 7 | Power Supply | 230 V AC, +/- 10% (other options on demand) |
| 8 | Mounting | Wall Mounting and Hanging for ceiling both options in-built |
| 9 | Dimensions | 608 x 168 mm, Depth: 70 mm |
| 10 | Optional | Available in Panel Mounting 610 x 170 mm cutout |
